| Processor / System Bus | 2 x LGA 4710 sockets
Intel® Xeon® 6500/6700 processors
Up to 350 TDP |
Memory
| Total Slots:
32 (8 channel per CPU, 16 DIMM per CPU)
Capacity:
Maximum up to 4TB
Memory Type:
DDR5 6400 (1DPC) / 5200 (2DPC) RDIMM
Memory Size:
128GB, 96GB, 64GB, 32GB RDIMM
* Refer to ASUS server AVL for the latest update |
| Expansion Slots | -8 x PCIe x 16 for dual-slot GPU cards (Gen5 x 16 link, FHFL)
-5 x PCIe x 16 for NIC/ BlueField-3 cards (Gen5 x 16 link, FHFL)
-1 x PCIe x 16 (Gen5 x 8 link, FHHL) |
Storage
| 8 x 2.5" Front Hot-swap Storage Bays
(Backplane supports up to 8 x NVMe)
2 x M.2 socket (Gen 5 x4 link, up to 22110) |
| Networking | 2 x 10GbE LAN ports (RJ45, X710-AT2)
1 x Management Port (RJ45) |
| Multi-GPU Support | Please find the latest GPU support from
https://servers.asus.com/support/gpu |
Front I/O Ports
| 1 x Mini DisplayPort
2 x USB 5Gbps ports
1 x Debug port
|
Rear I/O Ports
| 1 x USB 5Gbps port
2 x RJ-45 LAN ports
1 x RJ-45 management LAN port
|
Switch/LED
| Front:
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
1 x Clear CMOS switch
1 x Reset switch
2 x M.2 LEDs
2 x LAN LEDs
1 x Q-Code/Port 80 LED
Rear:
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
|
OS Support
| Please find the latest OS support from
https://servers.asus.com/support/os
|
Management Solution
| ASUS Control Center Enterprise (in-band)
ASMB12-iKVM for (out-of-band/BMC AST2600)
|
Regulatory Compliance
| BSMI, CB, CE, FCC(Class A), RCM
|
Dimensions
| 800mm x 439.5mm x 175mm
31.5” x 17.3” x 6.9” |
| Form Factor | 4U
|
Weight
| Net Weight: 42 Kg
Gross Weight: 44.23 Kg
|
| Power Supply | 3+1 redundant 3200W 80 PLUS Titanium power supply
20-240 Vac, 16A (x4) 50/60Hz |
| Environment | Operating temperature: 10°C ~ 35°C*
Non-operating temperature: -40°C ~ 60°C
Non-operating humidity: 20% ~ 95% (Non-condensing)
*For operating temperatures above 30°C, please contact your local sales representative |
