| Form Factor | 4U Rackmount
Enclosure: 446 x 174 x 900mm (17.6" x 6.9" x 35.4")
Package: 695 x 750 x 1140mm (27.4" x 29.5" x 44.9") |
Processor
| Dual SP3
AMD EPYC™ 7002/7003 Series Processors |
| GPU | Max GPU Count: 8 onboard GPUs
Supported GPU: NVIDIA SXM: HGX A100 8-GPU (80GB)
GPU-GPU Interconnect: NVIDIA® NVLink® with NVSwitch |
| System Memory | Slot Count: 32 DIMM slots
Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
| Drive Bays Configuration | Default: Total 6 bays
6 front hot-swap 2.5" NVMe drive bays
Option A: Total 10 bays
6 front hot-swap 2.5" NVMe drive bays
4 rear hot-swap 2.5" NVMe drive bays
M.2: 2 M.2 NVMe slots (M-key |
| Expansion Slots | PCI-Express (PCIe) Configuration: Default
1 PCIe 4.0 x16 LP slot
1 PCIe 4.0 x8 LP slot
M.2: 2 M.2 PCIe 4.0 x4 slots (M-key 22110) |
| On-Board Devices | Chipset: System on Chip
Network Connectivity: Ethernet
IPMI: Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
|
Input / Output
| LAN: 1 RJ45 1 GbE Dedicated BMC LAN port
USB: 2 USB 3.0 ports(front)
Video: 1 VGA port(Front)
|
System Cooling
| Fans: Up to 4 x Hot-swap 11.5K RPM heavy duty Fan(s)
|
Power Supply
| 4x 3000W Redundant (2 + 2) Titanium Level (96%) power supplies
|
System BIOS
| BIOS Type: AMI 256MB SPI Flash ROM
|
Management
| Supermicro Server Manager (SSM); Supermicro Power Manager (SPM); Supermicro Update Manager (SUM);
Supermicro SuperDoctor® 5 (SD5); KVM with dedicated LAN ; IPMI 2.0; Watch Dog
|
PC Health Monitoring
| CPU: Monitors for CPU Cores, Chipset Voltages, Memory
4+1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment
Thermal Control for fan connectors
|
Dimensions and Weight
| Weight: Gross Weight: 225 lbs (102.1 kg)
Net Weight: 166 lbs (75.3 kg)
Available Color: Black Front & Silver Body
|
Operating Environment
| RoHS Compliant
Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (Non-Condensing)
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
|
