| Form Factor | 4U Rackmount
Enclosure: 449 x 175.6 x 833mm (17.67" x 7" x 32.79")
Package: 700 x 370 x 1260mm (27.55" x 14.57" x 49.6") |
Processor
| Dual Socket SP3
AMD EPYC™ 7003 Series
Up to 128C/256T |
| GPU | Max GPU Count: 4 onboard GPUs
Supported GPU: AMD: Instinct™ MI250 Accelerators, Instinct™ MI250 Accelerators, Instinct™ MI250 Accelerators
CPU-GPU Interconnect: PCIe 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect: AMD Infinity Fabric™ Link
|
System Memory
| Slot Count: 32 DIMM slots/8 Channels
Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
| Drive Bays Configuration | Default: Total 10 bays
10 front hot-swap 2.5" NVMe/SAS/SATA drive bays |
| Expansion Slots | Default
8 PCIe 4.0 x16 via PLX slots
Option A*
8 PCIe 4.0 x16 via PLX slots
2 PCIe 4.0 x16 LP slots |
On-Board Devices
| Chipset: System on Chip
Network Connectivity: Via AIOM
IPMI: Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
|
Input / Output
| LAN: 1 RJ45 1 GbE Dedicated BMC LAN port
USB: 2 USB 3.0 ports(front)
Video: 1 VGA port(Front)
Serial: 1 COM port
|
System Cooling
| Fans: Up to 5 x hot-swap 11.5K RPM heavy duty Fan(s)
|
Power Supply
| 4x 3000W Redundant (2 + 2) Titanium Level (96%) power supplies
|
System BIOS
| BIOS Type: AMI 256MB SPI Flash ROM
|
Management
| Supermicro Server Manager (SSM); Supermicro Power Manager (SPM); Supermicro Update Manager (SUM);
Supermicro SuperDoctor® 5 (SD5); KVM with dedicated LAN ; IPMI 2.0; Watch Dog
|
PC Health Monitoring
| CPU: Monitors for CPU Cores, Chipset Voltages, Memory
4+1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
|
Dimensions and Weight
| Weight: Gross Weight: 140 lbs (64 kg)
Net Weight: 105 lbs (48 kg)
Available Color: Black Front & Silver Body
|
Operating Environment
| RoHS Compliant
Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (Non-Condensing)
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
|
