| Form Factor | 5U Rackmount
Enclosure: 438 x 222.5 x 786.1mm (17.2" x 8.75" x 31")
Package: 720 x 440 x 1080mm (28.34" x 17.32" x 42.51") |
Processor
| Dual processor(s)
AMD EPYC™ 9005/9004 Series Processors
Up to 192C/384T |
| GPU | Max GPU Count: Up to 8 double-width GPUs
Supported GPU: NVIDIA PCIe: H100 NVL, NVIDIA RTX PRO™ 6000 Blackwell Server Edition, H200 NVL (141GB), L40S
CPU-GPU Interconnect: Direct Attached
GPU-GPU Interconnect: NVIDIA® NVLink® Bridge (optional), AMD Infinity Fabric™ Link (optional)
|
System Memory
| Slot Count: 24 DIMM slots
Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor)
Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) |
| Drive Bays Configuration | Default: Total 6 bays
2 front hot-swap 2.5" SATA drive bays
4 front hot-swap 2.5" NVMe drive bays
Option A: Total 2 bays
2 front hot-swap 2.5" SATA drive bays
M.2: 1 M.2 PCIe 3.0 x4 NVMe slot (M-key) |
| Expansion Slots | Default
9 PCIe 5.0 x16 FHFL double-width slots
Option A
10 PCIe 5.0 x16 FHFL double-width slots |
On-Board Devices
| SATA: SATA (6Gbps)
Chipset: System on Chip
Network Connectivity: 2 RJ45 10GbE
|
Input / Output
| LAN: 1 RJ45 1 GbE Dedicated BMC LAN port
2 RJ45 10 GBASE-T LAN ports
USB: 2 ports(rear)
Video: 1 VGA port
|
System Cooling
| Fans: 10 heavy duty fans with optimal fan speed control
|
Power Supply
| 6x 2700W Redundant (3 + 3) Titanium Level (96%) power supplies
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); Super
Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer Automation Assistant (SAA)
|
PC Health Monitoring
| CPU: Monitors for CPU Cores, Chipset Voltages, Memory
7 +1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment
Thermal Control for fan connectors
|
Dimensions and Weight
| Weight: Gross Weight: 100 lbs (45.3 kg)
Net Weight: 65.5 lbs (29.7 kg)
Available Color: Black Front & Silver Body
|
Operating Environment
| Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
Chassis
| Chassis CSE-528G2TS-R000NDP
|
