| Form Factor | 2U Rackmount
Enclosure: 447 x 88 x 760mm (17.6" x 3.47" x 29.9")
Package: 600 x 240 x 1100mm (23.62" x 9.44" x 43.3") |
Processor
| Single Socket P+ (LGA-4189)
3rd Gen Intel® Xeon® Scalable processors
Up to 40C/80T; Up to 60MB Cache |
| GPU | Max GPU Count: Up to 3 double-width or 3 single-width GPUs
Supported GPU: NVIDIA PCIe: A40, RTX A4500, RTX A4000, A40, A30, A100, A10
CPU-GPU Interconnect: PCIe 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect: PCIe |
System Memory
| Slot Count: 8 DIMM slots
Max Memory (2DPC): Up to 1TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
| Drive Bays Configuration | Default: Total 2 bays
2 front hot-swap 2.5" NVMe drive bays
M.2: 2 M.2 NVMe/SATA slots (M-key |
| Expansion Slots | Default
3 PCIe 4.0 x16 FHFL double-width slots |
On-Board Devices
| Chipset: Intel® C621A
Network Connectivity: Via AIOM
|
System Cooling
| Fans: Up to 4 Removable heavy-duty Fan(s)
|
Power Supply
| 1x 2600W Redundant Titanium Level (96%) power supply
|
System BIOS
| BIOS Type: AMI 32MB SPI Flash EEPROM
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); Supermicro
SuperDoctor® 5 (SD5); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer
Automation Assistant
|
PC Health Monitoring
| CPU: Monitors for CPU Cores, Chipset Voltages, Memory
7 +1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment
Thermal Control for fan connectors
|
Dimensions and Weight
| Weight: Gross Weight: 60 lbs (27.21 kg)
Net Weight: 55 lbs (24.94 kg)
Available Color: Black Front & Silver Body
|
Operating Environment
| tOperating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
Chassis
| Chassis CSE-227GTS-R2K63P
|
