| Form Factor | 4U Rackmount
Enclosure: 446 x 174 x 900mm (17.6" x 6.9" x 35.4")
Package: 695 x 750 x 1140mm (27.4" x 29.5" x 44.9") |
Processor
| Dual Socket P+ (LGA-4189)
3rd Gen Intel® Xeon® Scalable processors
Up to 40C/80T; Up to 60MB Cache per CPU |
| GPU | Max GPU Count: 8 onboard GPUs
Supported GPU: NVIDIA SXM: HGX A100 8-GPU (80GB)
CPU-GPU Interconnect: PCIe 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect: NVIDIA® NVLink® with NVSwitch |
System Memory
| Slot Count: 32 DIMM slots
Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Supports Intel® Optane™ persistent memory 200 series |
| Drive Bays Configuration | Default: Total 6 bays
6 front hot-swap 2.5" NVMe/SAS/SATA drive bays
M.2: 2 M.2 NVMe/SATA slots (M-key) |
| Expansion Slots | Default
10 PCIe 4.0 x16 LP slots |
On-Board Devices
| SATA: SATA (6Gbps) ; RAID 0/1/5/10 support
Chipset: Intel® C621A
Network Connectivity: 2 RJ45 10GbE with Intel® X550-AT2 (optional)
|
Input / Output
| 1 VGA port
|
System Cooling
| Fans: Up to 4 heavy duty fans with optimal fan speed control
|
Power Supply
| 1x 3000W Redundant Titanium Level (96%) power supply
|
System BIOS
| BIOS Type: AMI 32MB SPI Flash EEPROM
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); Supermicro
SuperDoctor® 5 (SD5); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer
Automation Assistant (SAA) New!
|
Dimensions and Weight
| Weight: Gross Weight: 225 lbs (102.1 kg)
Net Weight: 166 lbs (75.3 kg)
Available Color: Black Front & Silver Body
|
Operating Environment
| Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
Chassis
| CSE-438G
|
