| Form Factor | 4U Rackmount
Enclosure: 437 x 178 x 737mm (17.2" x 7" x 29")
Package: 685 x 675 x 1041mm (27" x 26.57" x 41") |
| Processor | Dual Socket P+ (LGA-4189)
3rd Gen Intel® Xeon® Scalable processors
Up to 40C/80T; Up to 60MB Cache per CPU |
| GPU | Max GPU Count: Up to 10 double-width or 10 single-width GPUs
Supported GPU:
NVIDIA PCIe: H100, L40, RTX A5500, A40, RTX A6000, RTX A5000, RTX A4500, RTX A4000, RTX A2000, A40, A30, A16,
A2, A100, A10
Intel PCIe: Intel Data Center GPU Flex 170
CPU-GPU Interconnect: PCIe 4.0 x16 Switch Dual-Root
GPU-GPU Interconnect: NVIDIA® NVLink® Bridge (optional) |
System Memory
| Slot Count: 32 DIMM slots
Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Supports Intel® Optane™ persistent memory 200 series |
| Drive Bays Configuration | Default: Total 24 bays
8 front hot-swap 2.5" NVMe drive bays
16 front hot-swap 2.5" SAS/SATA drive bays
Option A: Total 24 bays
24 front hot-swap 2.5" NVMe*/SAS/SATA drive bays
(*NVMe support may require additional storage controller and/or cables, please see the optional parts list for
details)
M.2: 2 M.2 NVMe/SATA slots (M-key) |
| Expansion Slots | Default
12 PCIe 4.0 x16 FHFL slots |
On-Board Devices
| SATA: SATA (6Gbps) ; RAID 0/1/5/10 support
Chipset: Intel® C621A
Network Connectivity: 2 RJ45 1GbE with Intel® I350
|
Input / Output
| 1 VGA port
|
System Cooling
| Fans: Up to 8 heavy duty fans with optimal fan speed control
|
Power Supply
| 4x 2000W Redundant Titanium Level (96%) power supplies
|
System BIOS
| BIOS Type: AMI 32MB SPI Flash EEPROM
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); Supermicro
SuperDoctor® 5 (SD5); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer
Automation Assistant (SAA) New!
|
PC Health Monitoring
| CPU: Monitors for CPU Cores, Chipset Voltages, Memory
7 +1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment
Thermal Control for fan connectors
|
Dimensions and Weight
| Weight: Gross Weight: 100 lbs (45.3 kg)
Net Weight: 65.5 lbs (29.7 kg)
Available Color: Black Front & Silver Body
|
Operating Environment
| Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
