| Processor / System Bus | 2 x Socket P+ (LGA 4189)
3rd Gen Intel® Xeon® Scalable Processors Family(235W) |
Memory
| Total Slots :
16 (8-channel per CPU, 8 DIMM per CPU)
Capacity :
Maximum up to 2048GB RDIMM
Memory Type :
DDR4 3200 RDIMM
DDR4 3200 LRDIMM
DDR4 3200 LR-DIMM 3DS
Memory Size :
128GB, 64GB, 32GB, 16GB
* Refer to support page for more information |
| Expansion Slots | Rear
- 4 x PCIe x16 slots (Gen4 x16 link, FH,FL) for dual-slot GPU cards or
8 x PCIe x16 slots (Gen4 x8 link, FH,FL) for single-slot GPU cards*
- 2 x PCIe x16 slots (Gen4 x16 link, LP,HL)
Front
- SKU-1:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL)
- SKU-2:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL) or
1 x OCP3.0 slot (Gen4 x16 link) by switching cables
- SKU-3:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL) or
2 x M.2 sockets (Gen4 x4 link, up to 22110 module) by switching cables |
Storage
| Storage Controller :
Intel® PCH C621A
Optional kits Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G HBA card
ASUS PIKE II 3108-8i 8-port SAS 12G RAID card |
| Networking | 2 x 1GbE LAN ports (RJ45, Intel I350-AM2) |
| Front | I/O Ports 4 x USB 3.2 Gen1 ports |
| Rear I/O Ports | 2 x USB 3.2 Gen1 ports
1 x VGA port
2 x 1GbE LAN ports (RJ45)
1 x Management port (RJ45)
|
Switch/LED
| Front :
1 x Power Button/LED
1 x Location Button/LED
2 x LAN LED
1 x Message LED
1 x HDD Access LED
Rear :
1 x Power Button/LED
1 x Location LED
1 x Message LED
1 x HDD Access LED
|
Management Solution
| ASUS Control Center Enterprise (in-band)
ASMB10-iKVM (out-of-band/BMC AST2600)
|
Regulatory Compliance
| BSMI, CB, CE, RCM, FCC(Class A)
|
Dimensions
| 800 x 440 x 88.9mm
|
Form Factor
| 2U
|
Net Weight
| 34 Kg Gross Weight: 44 Kg.
|
Power Supply
| 1+1 Redundant 1600W 80 PLUS Platinum Power Supply C-14 power inlet
Rating: 100-127Vac/200-240Vac,12.9A/9.5A,50-60Hz
1+1 Redundant 2200W 80 PLUS TITANIUM Power Supply C-20 power inlet
Rating: 100-127Vac/200-240Vac,14A/12.6A,47-63Hz
|
Environment
| Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
|
