| Form Factor | 4U Rackmount
Enclosure: 438.4 x 176 x 800mm (17.26" x 6.93" x 31.5")
Package: 1255 x 694 x 495mm (49.41" x 27.32" x 19.49") |
Processor
| Dual Socket BR (LGA-7529)
Intel® Xeon® 6900 series processors with P-cores
72C/144T |
| GPU | Max GPU Count: Up to 8 double-width GPUs
Supported GPU: NVIDIA PCIe: H100 NVL, NVIDIA RTX PRO™ 6000 Blackwell Server Edition, H200 NVL (141GB), L40S
CPU-GPU Interconnect: PCIe 5.0 x16 Switch Dual-Root
GPU-GPU Interconnect: NVIDIA® NVLink® Bridge (optional) |
System Memory
| Slot Count: 24 DIMM slots
Max Memory (1DPC): 6.0TB 6400MT/s ECC DDR5 RDIMM
Max Memory (1DPC): 6.0TB 8800MT/s ECC DDR5 MRDIMM |
| Drive Bays Configuration | Default: Total 8 bays
8 front hot-swap E1.S NVMe drive bays
M.2: 2 M.2 PCIe 4.0 x4 NVMe slots (M-key 2280(default)) |
| Expansion Slots | Default
8 PCIe 5.0 x16 FH double-width slots
4 PCIe 5.0 x16 HHHL slots
Option A
1 PCIe 5.0 x16 FHHL slot |
On-Board Devices
| Chipset: System on Chip
Network Connectivity: 1 RJ45 1GBASE-T with ASPEED AST2600
|
Input / Output
| USB: 1 USB 3.0 Type-A port(Rear)
Video: 1 mini-DP port
TPM: 1 TPM header
|
System Cooling
| Fans: Up to 10 Fan 80mm Fan(s)
|
Power Supply
| 4x 3200W Redundant (3 + 1) Titanium Level (96%) power supplies
|
System BIOS
| BIOS Type: AMI 32MB UEFI
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Super Diagnostics Offline (SDO); Supermicro ThinAgent Service (TAS); SuperServer Automation Assistant (SAA) New!
|
Dimensions and Weight
| Weight: Gross Weight: 96.45 lbs (43.75 kg)
Net Weight: 49.5 lbs (22.45 kg)
Available Color: Silver
|
Operating Environment
| Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
