| Processor / System Bus | 2 x Socket
6th Intel® Xeon® Processor Scalable Family (Up to 350W) |
Memory
| Total Slots:
32 (8 channel per CPU, 16 DIMM per CPU)
Capacity:
Maximum up to 4TB per CPU socket
Memory Type:
DDR5 6400 RDIMM/ 3DS RDIMM (2DPC)
Memory Size:
128GB, 96GB, 64GB
* Refer to support page for more information |
| Expansion Slots | SKU1: 4 x PCIe Gen5 slots
SKU2: 5 x PCIe Gen5 slots
[PCIe Switch directly]
-4 x PCIe Gen5 x16 link
-1 x PCIe Gen5 x8 link (Raid Only)
*Support PCIe x16 link support DPU
** For Raid card to connect storage |
Storage
| Optional Kits:
-Broadcom MegaRAID 9540-8i |
| Networking | 2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller)
1 x Management Port |
| Multi-GPU Support | NVIDIA HGX B300 288GB 8-GPU Baseboard |
| Front I/O Ports | 2 x USB 3.2 ports
1 x VGA port
2 x 10GbE RJ45 LAN port
1 x RJ-45 Mgmt LAN port
|
Switch/LED
| Front :
1 x Power Switch/LED
1 x Location Switch/LED
1 x Message LED
1 x Port80 LED (Q-Code)
LAN 1-2 LED (on NIC module
|
OS Support
| Please find the latest OS support from https://servers.asus.com/support/os
|
Management Solution
| ASUS Control Center
On-Board ASMB11-iKVM
|
Regulatory Compliance
| CB, CE, FCC, BSMI
|
Dimensions
| 945mm * 447mm * 394.5 mm
|
Form Factor
| 9U
|
Weight
| Net Weight kg (CPU, DRAM & HDD not included): 120kg
Gross Weight kg(CPU, DRAM & HDD not included,
Packing include): 150kg
|
Power Supply
| 5+5 3200W 80 PLUS Titanium Power Supply
|
