| System |
| Form Factor | 8U Rackmount |
| Dimensions | 930 x 448 x 353.6mm (36.6'' x 17.6'' x 13.9'') |
| Support MB | GNR2D32G-2L+ |
| Front Panel |
| Buttons | UID button w/ LED, power button w/ LED, reset button, NMI button |
| LEDs | System fault LED, HDD activity LED |
| I/O Ports | 8 OSFP (800Gb/s) via NVIDIA® ConnectX-8 SuperNIC
2 RJ45 (1GbE) by Intel i350, shared with Rear IO
1 dedicated IPMI, shares with Rear IO
4 Type-A (USB3.2 Gen1)
1 DB15 (VGA) |
| External Drive Bay / Storage |
| Front Side Drive Bay | 12 Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays [PCIe switch] |
| Internal Side | 1 M-key (PCIe5.0 x2), supports 22110/2280 form factor [CPU0]
2 M-key (PCIe5.0 x4), supports 22110/2280 form factor [CPU1] |
| Power Supply |
| Type | 6+6 CRPS |
| Output Watts | 3002.4W @ 220-240Vac input, 2900W @200-220Vac input |
| Efficiency | 80-PLUS Titanium |
| AC Input | 200-240Vrms, 50/60Hz |
| System Fan |
| Fan | 26 PWM 80x80 mm fans, 6 PWM 60x56 mm fans |
| Processor System |
| GPU | NVIDIA® HGX™ B300 NVL8 |
| CPU | Supports Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series Processors |
| Socket | 1+1 Socket E2 (LGA 4710) |
| | |
| Chipset | System on Chip |
| System Memory |
| Supported DIMM Quantity | 16+16 DIMM slots (2DPC) |
| Supported Type | DDR5 RDIMM, RDIMM-3DS
DDR5 MRDIMM (1DPC only) |
| Max. Capacity per DIMM | RDIMM: 128GB
RDIMM-3DS: 256GB
MRDIMM: 64GB |
| Max. DIMM Frequency | RDIMM, RDIMM-3DS: 6400MT/s (1DPC), 5200MT/s (2DPC)
MRDIMM: 8000MT/s (1DPC only) |
| Voltage | 1.1V |
| PCIe Expansion Slots |
| PCIe x 16 | Rear: 4FHHL PCIe5.0 x16 [PCIe switch] |
| Ethernet |
| Additional GbE Controller | Intel® i350: 2 RJ45 (1GbE)
NVIDIA® ConnectX-8 SuperNIC: 8 OSFP (800Gb/s) |
| Server Management |
| BMC Controller | ASPEED AST2600 |
| IPMI Dedicated GLAN | 1 Realtek RTL8211F for dedicated management GLAN |
| Graphics |
| Controller | ASPEED AST2600 |
| VRAM | DDR4 512MB |
| Rear I/O |
| UID Button/LED | 1 UID button w/LED |
| Other Button/LED | 1 power button w/LED, 1 reset button, 1 NMI button, 1 HDD activity LED, 1system fault LED |
| Video Port | 1 DB15 (VGA) |
| USB 3.2 Gen1 Port | 2 Type-A (USB3.2 Gen1) |
| RJ45 | 2 RJ45 (1GbE) by Intel® i350, shared with front IO
1 dedicated IPMI, shared with front IO |
| System BIOS |
| BIOS Type | AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM |
| BIOS Features | Plug and Play, ACPI 4.0 and above compliance wake up events, SMBIOS 3.4 and above, ASRock Rack instant flash |
| Hardware Monitor |
| Temperature | CPU, MB, Card side Temperature Sensing |
| Fan | Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
Fan Multi-Speed Control |
| Voltage | P0_VDDCR_CPU0, P0_VDDCR_CPU1, P0_VDDCR_SOC, P0_VDD_18_DUAL, P0_VDD_11_S3, P0_VDDIO, P1_VDDCR_CPU0, P1_VDDCR_CPU1, P1_VDDCR_SOC, P1_VDD_18_DUAL, P1_VDD_11_S3, P1_VDDIO, +BAT, +12V, +3VSB, +5VSB |
| Environment |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
| Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
