| Processor / System Bus | 2 x Socket SP5 (LGA 6096)
AMD EPYC™ 9005 series processors*
* Up to 500W cTDP, TDP support varies by configuration |
Memory
| Total Slots:
24 (12 channel per CPU, 12 DIMM per CPU)
Capacity:
Maximum up to 3TB
Memory Type:
DDR5 6400/5600 RDIMM
Memory Size:
128GB, 96GB, 64GB, 32GB, 16GB RDIMM |
| Expansion Slots | Up to 11 slots Rear:
8 x PCIe x16 for dual-slot GPU cards (Gen5 x16 link, FH/FL)
1 x PCIe x16 for NIC/BlueField-3 card (Gen5 x16 link, FH/HL)
1 x PCIe x16 for NIC card (Gen5 x8 link, FH/HL) Front:
1 x PCIe x16 for HBA/RAID card (Gen5 x8 link, FH/HL) |
Storage
| 8 x 2.5" Front Hot-swap Storage Bays
*Backplane supports up to 4 or 6 NVMe drives based on HBA/Raid card model installed |
| Networking | 1 x Management Port |
| Front I/O Ports | 1 x Mini DisplayPort
2 x USB 5Gbps ports
1 x Debug port |
Rear I/O Ports
| 1 x USB 5Gbps port
1 x RJ-45 management LAN port
|
Switch/LED
| Front :
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
1 x Clear CMOS switch
1 x Reset Switch
2 x M.2 LEDs*
2 x LAN LEDs*
1 x Q-code/Port 80 LED
Rear :
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
*ESC8000A-E13P only
|
Management Solution
| ASUS Control Center Enterprise (in-band)
ASMB12-iKVM for (out-of-band/BMC AST2600)
|
Regulatory Compliance
| BSMI, CB, CE, FCC(Class A), RCM
|
Dimensions
| 800mm x 439.5mm x 175mm
31.5” x 17.3” x 6.9”
|
Weight
| Net Weight: 42 Kg
Gross Weight: 44.23 Kg
|
Power Supply
| 3+1 redundant 3200W 80 PLUS Titanium power supply
20-240 Vac, 16A (x4) 50/60Hz |
Environment
| Operating temperature: 10°C ~ 35°C
Non-operating temperature: -40°C ~ 60°C
Non-operating humidity: 20% ~ 95% (Non-condensing)
|
Form Factor
| 4U
|
