| Processor / System Bus | 2 x LGA 4710 sockets
Intel® Xeon® 6 processors
*Up to 350 TDP |
Memory
| Total Slots:
32 (8 channel per CPU, 16 DIMM per CPU)
Capacity:
Maximum up to 4TB
Memory Type:
DDR5 6400 (1DPC) / 5200 (2DPC) RDIMM
Memory Size:
128GB, 96GB, 64GB, 32GB RDIMM
* Refer to ASUS server AVL for the latest update |
| Expansion Slots | SKU1 (with RAID)
-8 x PCIe x 16 for dual-slot GPU cards (Gen5 x 16 link, FHFL)
-1 x PCIe x 16 for NIC/BlueField-3 cards (Gen5 x 16 link, FHFL)
-1 x PCIe x 16 for NIC cards (Gen5 x 8 link, FHHL)
-1 x PCIe x 16 for HBA/RAID cards (Gen5 x 8 link, FHHL) SKU2 (w/o RAID)
-8 x PCIe x 16 for dual-slot GPU card (Gen5 x 16 link, FHFL)
-1 x PCIe x 16 for NIC/BlueField-3 card (Gen5 x 16 link, FHFL)
-1 x PCIe x 16 for NIC card (Gen5 x 8 link, FHHL) |
Storage
| 8 x 2.5" Front Hot-swap Storage Bays SKU1 (with RAID) up to 6 NVMes devices (requires HBA/RAID card)
SKU2 (w/o RAID) up to 4 NVMes |
| Networking | 1 x Management Port |
| Front I/O Ports | 1 xMini DisplayPort
2 xUSB 5Gbps ports
1 x Debug port |
Rear I/O Ports
| 1 x USB 5Gbps port
1 x RJ-45 management LAN port
|
Switch/LED
| Front :
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED
1 x Clear CMOS switch
1 x Reset Switch
2 x M.2 LEDs*
1 x Q-code/Port 80 LED Rear :
1 x Power switch/LED
1 x Location switch/LED
1 x Message LED |
Management Solution
| ASUS Control Center Enterprise (in-band)
ASMB12-iKVM for (out-of-band/BMC AST2600)
|
Regulatory Compliance
| BSMI, CB, CE, FCC(Class A), RCM
|
Dimensions
| 800mm x 439.5mm x 175mm
31.5” x 17.3” x 6.9”
|
Form Factor
| 4U
|
Weight
| Net Weight: 42 Kg
Gross Weight: 44.23 Kg |
Power Supply
| 3+1 redundant 3200W 80 PLUS Titanium power supply
20-240 Vac, 16A (x4) 50/60Hz
|
Environment
| Operating temperature: 10°C ~ 35°C
Non-operating temperature: -40°C ~ 60°C
Non-operating humidity: 20% ~ 95% (Non-condensing)
|
