| Form Factor | 2U Rackmount
Enclosure: 437 x 88.9 x 806.2mm (17.2" x 3.5" x 31.74")
Package: 672 x 253 x 1100mm (26.46" x 9.96" x 43.31") |
Processor
| Dual processor(s)
AMD EPYC™ 9005/9004 Series Processors
Up to 384C/768T |
| GPU | Max GPU Count: Up to 3 double-width GPUs
Supported GPU: NVIDIA PCIe: H100 NVL, RTX 6000 Ada Generation, L4
GPU-GPU Interconnect: PCIe |
| System Memory | Slot Count: 24 DIMM slots
Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor)
Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) |
| Drive Bays Configuration | Default: Total 8 bays
8 front hot-swap 2.5" NVMe*/SATA* drive bays
Option A: Total 24 bays
24 front hot-swap 2.5" NVMe*/SATA* drive bays
(*NVMe/SATA support may require additional storage controller and/or cables, please see the optional parts list
for details)
M.2: 2 M.2 PCIe 3.0 x4 NVMe slots (M-key 2280/22110) |
| Expansion Slots | PCI-Express (PCIe) Configuration: Option A*
4 PCIe 5.0 x16 FHFL double-width slots
1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible)
Option B*
8 PCIe 5.0 x8 (in x16) FHFL slots
1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible)
CXL Support: Up to 4 CXL 2.0 x16 devices |
On-Board Devices
| Chipset: System on Chip
Network Connectivity: Via AIOM
IPMI: Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
|
Input / Output
| LAN: 1 RJ45 1 GbE Dedicated BMC LAN port
USB: 2 USB 3.0 ports(rear)
Video: 1 VGA port
TPM: 1 TPM Onboard/port 80
|
System Cooling
| Fans: Up to 6 counter-rotating 60x60x56mm Fan(s)
Air Shroud: 2 Air Shrouds
|
Power Supply
| 2x 2000W Redundant (1 + 1) Titanium Level (96%) power supplies
|
System BIOS
| BIOS Type: AMI 64MB SPI Flash EEPROM
BIOS Features: Plug and Play (PnP)
UEFI 2.8
USB Keyboard support
ACPI 6.5
SMBIOS 3.7 or later
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Super Diagnostics Offline (SDO); KVM with dedicated
LAN ; IPMI 2.0; Supermicro Thin-Agent Service (TAS); SuperServer Automation Assistant (SAA) New!; IPMIView
|
PC Health Monitoring
| FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment
Thermal Control for fan connectors
Voltage:
System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU
thermal trip support
|
Dimensions and Weight
| Weight: Gross Weight: 75 lbs (34 kg)
Net Weight: 45 lbs (20.5 kg)
Available Color: Silver
|
Operating Environment
| Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
