| Dimensions | 1U (W438 x H43.5 x D815 mm) |
Motherboard
| MZG3-GU0 |
| CPU | AMD EPYC 9005 Series Processors
AMD EPYC 9004 Series Processors
Single processor, cTDP up to 400W
- At 25°C ambient, cTDP up to 500W |
Socket
| 1 x LGA 6096 (Socket SP5) |
| Chipset | System on Chip |
| Memory | 12-Channel DDR5 RDIMM, 24 x DIMMs
[EPYC 9005] Up to 5200 MT/s (1DPC)
Up to 4400 MT/s (1R 2DPC), 4000 MT/s (2R 2DPC)
[EPYC 9004] Up to 4800 MT/s (1DPC), 3600 MT/s (2DPC) |
LAN
| 1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED AST2600
- 1 x Mini-DP
|
Storage
| Front hot-swap:
16 x E3.S Gen5 NVMe
Internal M.2:
2 x M.2 (2280/22110), PCIe Gen3 x2
|
RAID
| Require RAID add-in cards
|
PCIe Expansion
Slots
| 1 x FHFL PCIe Gen5 x16, for GPUs
1 x FHFL PCIe Gen5 x16
1 x FHHL PCIe Gen5 x16
1 x OCP NIC 3.0 PCIe Gen5 x16, Support NCSI
Blocked when a Dual slot GPU is installed
|
I/O Ports
| Front:
1 x USB 3.2 Gen1
Rear:
2 x USB 3.2 Gen1, 1 x Mini-DP, 1 x MLAN
|
Backplane Board
| PCIe Gen5 x4
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM012
|
Power Supply
| 1+1 2700W 80 PLUS Titanium redundant power supplies
AC Input: 100-240V
*The system power supply requires C19 power cord.
|
| System Fans | 2 x 40x40x56mm
6 x 40x40x56mm |
Operating
Properties | Operating: 10°C to 30°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing) |
| Packaging Content | 1 x R163-ZG6-AAL2
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (12VHPWR, 400mm)
1 x 2-Section Rail kit |
