| Dimensions | 1U (W438 x H43.5 x D520 mm) |
Motherboard
| MS33-DC0 |
| CPU | 5th Generation Intel Xeon Scalable Processors
4th Generation Intel Xeon Scalable Processors
Intel Xeon CPU Max Series
Single processor, TDP up to 350W |
Socket
| 1 x LGA 4677 (Socket E) |
| Chipset | Intel C741 |
| Memory | 8-Channel DDR5 RDIMM, 16 x DIMMs
[5th Gen Intel Xeon] Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC)
[4th Gen Intel Xeon] Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)
[Intel Xeon Max Series] Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC) |
LAN
| 1 x 1Gb/s LAN (1 x Intel I210-AT), Support NCSI
1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED AST2600
- 1 x Mini-DP
|
Storage
| Front hot-swap:
2 x 2.5" Gen4 NVMe/SATA/SAS
Internal M.2:
1 x M.2 (2280/22110), PCIe Gen3 x4
SAS card is required to support SAS drives
|
RAID
| Intel SATA RAID 0/1
Onboard VROC key header
|
PCIe Expansion
Slots
| 2 x FHHL PCIe Gen5 x16
2 x OCP NIC 3.0 PCIe Gen5 x16, Support NCSI
|
I/O Ports
| Front:
1 x USB 3.2 Gen1
Rear:
2 x USB 3.2 Gen1, 1 x Mini-DP, 1 x RJ45, 1 x MLAN
|
Backplane Board
| PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM010
|
Power Supply
| 1+1 800W 80 PLUS Titanium redundant power supplies
AC Input: 100-240V
|
System
Management | ASPEED AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface |
| System Fans | 5 x 40x40x56mm |
| Operating Properties | Operating: 10°C to 35°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing) |
