| Dimensions | 2U (W438 x H87.5 x D815 mm) |
Motherboard
| MZ93-FS1 |
| CPU | AMD EPYC™ 9005 Series Processors
AMD EPYC™ 9004 Series Processors
Dual processor, cTDP up to 240W
The EPYC 9005 series processors with a cTDP of 240W are supported
only under ambient temperatures of 25°C. |
Socket
| 2 x LGA 6096 (Socket SP5) |
| Chipset | System on Chip |
| Memory | 12-Channel DDR5 RDIMM, 24 x DIMMs
[EPYC 9005] Up to 6400 MT/s
[EPYC 9004] Up to 4800 MT/s |
LAN
| 2 x 1Gb/s LAN (1 x Intel I350-AM2), Support NCSI
1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED AST2600
- 1 x Mini-DP
|
Storage
| Front hot-swap:
8 x 3.5"/2.5" Gen5 NVMe/SATA/SAS-4
4 x 3.5"/2.5" SATA/SAS-4
Rear hot-swap:
4 x 2.5" SATA/SAS-4
SAS card is required to support SAS drives
|
RAID
| Require RAID add-in cards
Optional compatible RAID Cards:
NVMe RAID Cards with SupremeRAID™ by Graid Technology
RAID Card models: SR-1000-ED12
Support RAID 0/1/5/6/10
|
PCIe ExpansionSlots
| 2 x FHFL PCIe Gen5 x16, for GPUs
2 x FHHL PCIe Gen5 x16
2 x OCP NIC 3.0 PCIe Gen5 x16, Support NCSI
|
I/O Ports
| Front:
2 x USB 3.2 Gen1
Rear:
2 x USB 3.2 Gen1, 1 x Mini-DP, 2 x RJ45, 1 x MLAN
|
Backplane Board
| Front - CBP20C7: PCIe Gen5 x4 or SATA6Gb/s or SAS-4 24Gb/s
Rear- CBP2025: SATA6Gb/s or SAS-4 24Gb/s
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM010
|
Power Supply
| 1+1 2400W 80 PLUS Platinum redundant power supplies
AC Input: 100-240V
*The system power supply requires C19 power cord
|
| System Fans | 4 x 80x80x38mm |
Operating
Properties | Operating: 10°C to 30°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing) |
| Packaging Content | 1 x R283-Z97-AAF1
2 x CPU heatsinks
1 x Mini-DP to D-Sub cable
2 x GPU power cables (CPU 8pin, 350mm)
1 x 2-Section Rail kit |
