| Dimensions | 2U (W438 x H87 x D900 mm) |
Motherboard
| MSX4-MG0 |
| CPU | Intel Xeon 6 Processors
- Intel Xeon 6700-Series Processors
- Intel Xeon 6500-Series Processors
Dual processor, TDP up to 350W |
Socket
| 2 x LGA 4710 (Socket E2) |
| Chipset | System on Chip |
| Memory | 8-Channel DDR5 RDIMM/MRDIMM, 32 x DIMMs
[RDIMM] Up to 6400 MT/s (1DPC), 5200 MT/s (2DPC)
[MRDIMM] Up to 8000 MT/s |
LAN
| 2 x 10Gb/s LAN (1 x Intel X550-AT2), Support NCSI
1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED AST2600
- 1 x Mini-DP
|
Storage
| Front hot-swap:
4 x 2.5" Gen5 NVMe/SATA/SAS-4
Internal M.2:
2 x M.2 (2280/22110), PCIe Gen5 x2
|
RAID
| Onboard VROC key header
|
PCIe Expansion
Slots
| 4 x FHFL PCIe Gen5 x16, for GPUs
2 x FHFL PCIe Gen5 x16, for NICs
1 x FHFL PCIe Gen5 x16, for DPUs
|
I/O Ports
| Front:
2 x USB 3.2 Gen1
Rear:
2 x USB 3.2 Gen1, 1 x Mini-DP, 2 x RJ45, 1 x MLAN
|
Backplane Board
| PCIe Gen5 x4
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM012
1 x PRoT connector (only enabled on RoT SKU)
|
Power Supply
| 3+1 2000W 80 PLUS Titanium redundant power supplies
AC Input: 100-240V
|
| System Fans | 4 x 80x80x80mm |
Operating
Properties | Operating: 10°C to 35°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing) |
Packaging
Content | 1 x XV24-SX0-AAJ1
2 x CPU heatsinks
1 x Mini-DP to D-Sub cable
2 x GPU power cables (16-pin, 620mm)
2 x GPU power cables (16-pin, 750mm)
4 x Carriers
1 x 3-Section Rail kit |
