| Dimensions | 2U (W448 x H87.5 x D800 mm) |
Motherboard
| MZ43-G20 |
| CPU | AMD EPYC™ 9005 Series Processors
AMD EPYC™ 9004 Series Processors
Dual processor, TDP up to 210W
- At ambient 30°C, cTDP up to 240W |
Sock
| 2 x LGA 6096 (Socket SP5) |
| Chipset | System on Chip |
| Memory | 12-Channel DDR5 RDIMM, 24 x DIMMs
[EPYC 9005] Up to 6000 MT/s
[EPYC 9004] Up to 4800 MT/s |
LAN
| 2 x 10Gb/s LAN (1 x Broadcom® BCM57416) - Supports NCSI
1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED® AST2600
- 1 x VGA port
|
Storage
| Front hot-swap:
4 x 2.5" Gen5 NVMe/SATA/SAS
4 x 2.5" SATA/SAS
*SAS card is required to support SAS drives.
|
RAID
| Require RAID add-in cards
|
Expansion
Slots
| 4 x PCIe Gen5 x16 or 8 x PCIe Gen5 x8 FHFL slots for GPUs
2 x LP PCIe Gen5 x16 slots for add-in cards
Maximum GPU dimensions (LxWxH): 285 x 111.5 x 39.5mm.
The system is validated for use with a single GPU model.
|
Rear I/O Ports
| 2 x USB 3.2 Gen1, 1 x VGA, 2 x RJ45, 1 x MLAN
|
Backplane Board
| Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS 12Gb/s
|
Security Modules
| 1 x TPM header with SPI interface (Optional TPM2.0 kit: CTM010)
|
Power Supply
| Dual 3000W 80 PLUS Titanium redundant power supply
AC Input: 100-240V
The system power supply requires C19 power cord.
|
| System Management | ASPEED® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface |
| OS Support | Windows Server, Red Hat Enterprise Linux server, Ubuntu,
SUSE Linux Enterprise server, VMware ESXi, Citrix Hypervisor |
| System Fans | 8 x 80x80x38mm (18,300rpm) |
Operating
Properties | Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing) |
