| Dimensions | 4U (W448 x H176 x D880 mm) |
Motherboard
| MZ52-G42 Rev. 3.0 |
| CPU | AMD EPYC™ 7003 Series processors
Dual processors, 7nm technology,
Up to 64-core, 128 threads per processor
TDP up to 240W, cTDP up to 280W
Compatible with AMD EPYC™ 7002 Series processors |
Memory
| 8-Channel DDR4 memory, 32 x DIMM slots
RDIMM/LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
Memory speed: Up to 3200/ 2933 MHz |
| LAN | 2 x 1Gb/s LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN |
| Video | Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM |
| Storage | 12 x 3.5" or 2.5" hot-swappable HDD/SSD bays
- 4 x green HDD trays compatible with NVMe devices
- 4 x green HDD trays compatible with NVMe or SATA/SAS devices
- 4 x blue HDD trays compatible with SATA/SAS devices
SAS card is required for SAS devices support
|
Expansion Slots
| 10 x PCIe x16 (Gen4 x16) slots for GPUs
2 x PCIe x16 (Gen4 x16) Half-length low-profile slots
1 x PCIe x16 (Gen4 x8) Half-length low-profile slot
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16
|
Front I/O
| 2 x USB 3.0, 1 x VGA. 2 x RJ45, 1 x MLAN
|
Rear I/O
| N/A
|
Backplane I/O
| Backplane PN: 9CBP20C5NR-00 12 ports
Speed and bandwidth: SAS 12Gb/s, SATA 6Gb/s or PCIe Gen4
|
TPM
| 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
|
Power Supply
| 3 x 2200W redundant PSUs
AC Input: 100-240V
|
System Management
| Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X)
|
OS Compatibility
| Windows Server 2016 / 2019
RHEL 8.3 (x64) or later
SLES 12 SP5 (x64) / 15 SP2 (x64) or later
Ubuntu 18.04.5 LTS (x64) / 20.04 LTS (x64) or later
VMware ESXi 6.7 Update3 P03 / 7.0 Update1 or later
Citrix Hypervisor 8.2.0 or later
|
| System Fans | 4 x 40x40x28mm (25,000rpm)
1 x 55x55x7.5mm (6,000rpm)
12 x 60x60x38mm (21,700rpm) |
| Operating Properties | Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing) |
| Packaging Content | 1 x G492-Z52, 2 x CPU fan-sinks, 1 x Rail kit |
