| Main Specifications |
| Processor Support | 2 x Socket SP5 (LGA 6096)
AMD EPYC™ 9005 series processors*
*Up to 500 TDP, actual TDP support varies by configuration | |
| Core Logic | System on Chip (SOC) | |
| Total Slots | 24 x DIMM slots (12 channel per CPU, 12 DIMM per CPU) | |
| Capacity | Maximum up to 3TB | |
| Memory Type | DDR5 6400/5600 RDIMM
*Refer to ASUS server AVL for the latest update | |
| Memory Size | 128GB, 96GB, 64GB, 32GB, 16GB RDIMM
*Refer to ASUS server AVL for the latest update | |
| Total Slots | 10 | |
| Slot Type | Rear:
- 8 x PCIe x16 (Gen6 x16 link, FHFL) for dual-slot GPU cards
- 1 x PCIe x16 (Gen5 x16 link, FHHL) for NIC cards or NVIDIA BlueField®-3 DPUs
Front:
- 1 x PCIe x16 (Gen5 x8 link, FHHL) | |
| Storage Bays | 8 x 2.5" Front Hot-swap Storage Bays
Default SKU*: Backplane supports up to 8 x NVMe
RAID SKU: Backplane supports up to 4 or 6 NVMe drives based on HBA/Raid card
model installed
*MGX compliance
2 x M.2 socket (Gen 5 x4 link, up to 22110) | |
| LAN | 8 x 400 Gb/s ports (QSFP, NVIDIA ConnectX®-8 SuperNICs )
2 x 10GbE LAN ports (RJ45, X710-AT2)
1 x Management Port (RJ45) | |
| Multi-GPU Support | Multi-GPU Support Please find the latest GPU support from https://servers.asus.com/support/gpu | |
| VGA | Aspeed AST2600 64MB | |
| Front I/O Ports | 1 x Mini display port
2 x USB 5Gbps ports
1 x Debug port | |
| Rear I/O Ports | 8 x QSFP ports
1 x USB 5Gbps port
2 x RJ-45 LAN ports
1 x RJ-45 management LAN port | |
| Switch/LED | Front Switch/LED:
1 x Power switch/LED, 1 x Location switch/LED, 1 x Message LED,
1 x Clear CMOS switch, 1 x Reset switch, 2 x M.2 LEDs, 2 x LAN LEDs, 1 x Q-Code/Port
80 LED
Rear Switch/LED:
1 x Power switch/LED, 1 x Location switch/LED, 1 x Message LED | |
| Dimension | 800mm x 439.5mm x 175 mm (4U)
31.5’’x 17.3’’x 6.9’’ | |
| Power Supply | 3+1 Redundant 3200W 80 PLUS Titanium power
Rating: 220-240 Vac, 16A (x4) 50/60Hz | |
| Environment | Operating temperature: 10°C ~ 35°C
Non-operating temperature: -40°C ~ 60°C
Non-operating humidity: 20% ~ 95% (Non-condensing)
*For operating temperatures above 30°C, please contact your local sales
representative | |
