| Dimensions | 5U (W447 x H219.7 x D945 mm) |
Motherboard
| MSB3-G41 |
| CPU | 5th Generation Intel Xeon Scalable Processors
4th Generation Intel Xeon Scalable Processors
Intel Xeon CPU Max Series
Dual processor, TDP up to 350W |
| Socket | 2 x LGA 4677 (Socket E) |
| Chipset | Intel C741 |
| Memory | 8-Channel DDR5 RDIMM, 32 x DIMMs
[5th Gen Intel Xeon] Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC)
[4th Gen Intel Xeon] Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)
[Intel Xeon Max Series] Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC) |
LAN
| Front:
2 x 10Gb/s LAN (1 x Intel X710-AT2), Support NCSI
1 x 10/100/1000 Mbps Management LAN
Rear:
1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED AST2600
- 1 x VGA port
|
Storage
| 8 x 2.5" Gen5 NVMe/SATA/SAS-4
|
RAID
| Intel SATA RAID 0/1/10/5
Support optional RAID add-in cards
|
Modular GPU
| NVIDIA HGX H200 with 8 x SXM GPUs
|
PCIe Expansion Slots
| 4 x FHHL PCIe Gen5 x16
8 x LP PCIe Gen5 x16
|
I/O Ports
| Front:
2 x USB 3.2 Gen1, 1 x VGA, 2 x RJ45, 1 x MLAN (default)
Rear:
1 x MLAN |
| Backplane Board | PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM010
|
| Power Supply | 4+2 3000W 80 PLUS Titanium redundant power supplies
AC Input: 100-240V |
| System Management | ASPEED AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface |
| System Fans | Motherboard:
2 x 40x40x28mm
4 x 60x60x56mm
PCIe slots:
4 x 40x40x28mm
2 x 40x40x56mm
GPU tray:
6 x 60x60x76mm
11 x 80x80x80mm |
| Operating Properties | Operating: 10°C to 35°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing) |
