| Dimensions | 8U (W447 x H351 x D923 mm) |
Motherboard
| MSB3-PE0 |
| CPU | 5th Generation Intel Xeon Scalable Processors
4th Generation Intel Xeon Scalable Processors
Intel Xeon CPU Max Series
Dual processor, TDP up to 350W |
Socket
| 2 x LGA 4677 (Socket E) |
| Chipset | Intel C741 |
| Memory | 8-Channel DDR5 RDIMM, 32 x DIMMs
[5th Gen Intel Xeon] Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC)
[4th Gen Intel Xeon] Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)
[Intel Xeon Max Series] Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC) |
LAN
| Front:
2 x 10Gb/s LAN (1 x Intel X710-AT2), Support NCSI
1 x 10/100/1000 Mbps Management LAN
Rear:
1 x 10/100/1000 Mbps Management LAN
|
Video
| Integrated in ASPEED AST2600
- 1 x VGA port
|
Storage
| Front hot-swap:
8 x 2.5" Gen5 NVMe/SATA
Internal M.2:
1 x M.2 (2280/22110), PCIe Gen3 x2
1 x M.2 (2280/22110), PCIe Gen3 x1
|
Modular GPU
| Intel Gaudi 3 AI accelerators
- 8 x HL-325L OAM mezzanine cards
- 1 x HLB-325 baseboard
|
PCIe Expansion
Slots
| 4 x FHHL dual-slot PCIe Gen5 x16
8 x FHHL single-slot PCIe Gen5 x16
|
I/O Ports
| Front:
2 x USB 3.2 Gen1, 1 x VGA, 2 x RJ45, 1 x MLAN (default)
Rear:
1 x MLAN
|
Backplane Board
| PCIe Gen5 x4 or SATA 6Gb/s
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM012
|
Power Supply
| 5+5 3000W 80 PLUS Titanium redundant power supplies
AC Input: 115-240V
|
System
Management | ASPEED AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface |
| System Fans | Motherboard:
2 x 60x60x56mm
4 x 60x60x76mm
PCIe slots:
4 x 80x80x56mm
GPU tray:
16 x 80x80x80mm |
Operating
Properties | Operating: 10°C to 30°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing) |
