| Dimensions | 4U (W482.6 x H177 x D625 mm) |
CPU
| 5th Generation Intel Xeon Scalable Processors
4th Generation Intel Xeon Scalable Processors
Dual processor, TDP up to 270W |
| Socket | 2 x LGA 4677 (Socket E) |
Chipset
| Intel C741 |
| Memory | 8-Channel DDR5 RDIMM, 16 x DIMMs
[5th Gen Intel Xeon] Up to 5600 MT/s
[4th Gen Intel Xeon] Up to 4800 MT/s |
| LAN | 2 x 10Gb/s LAN (1 x Intel X710-AT2), Support NCSI
2 x 1Gb/s LAN (2 x Intel I210-AT), Support NCSI
1 x 10/100/1000 Mbps Management LAN |
Video
| Integrated in ASPEED AST2600
- 1 x VGA port
|
Storage
| Front hot-swap:
24 x 3.5"/2.5" SATA/SAS
Rear hot-swap:
12 x 3.5"/2.5" SATA/SAS
2 x 2.5" SATA/SAS , for boot drives
Internal M.2:
2 x M.2 (2280/22110), PCIe Gen4 x4
|
RAID
| Require RAID add-in cards
Onboard VROC key header
|
PCIe Expansion Slots
| 6 x LP PCIe Gen5 x16
|
I/O Ports
| Front:
2 x USB 3.2 Gen1
Rear:
2 x USB 3.2 Gen1, 1 x VGA, 4 x RJ45, 1 x MLAN
|
Backplane Board
| Front - CBPD4O0: SATA 6Gb/s or SAS 12Gb/s
Rear - CBP2021: SATA 6Gb/s or SAS 12Gb/s
Rear - CBPD0C0: SATA 6Gb/s or SAS 12Gb/s
|
TPM
| 1 x TPM header (SPI), Optional TPM2.0 kit: CTM010
|
Power Supply
| Dual 1600W 80 PLUS Titanium redundant power supply
AC Input: 100-240V
|
System Fans
| Operating: 10°C to 35°C, 8% to 80% (non-condensing)
Non-operating: -40°C to 60°C, 20% to 95% (non-condensing)
|
