| Form Factor | 4U Rackmount
Enclosure: (17.6" x 7" x 42.1")
Package: (35.82" x 29.92" x 53.15") |
Processor
| Dual Socket P+ (LGA-4189)
3rd Gen Intel® Xeon® Scalable processors
Up to 36C/72T; Up to 54MB Cache per CPU |
| System Memory | Slot Count: 16 DIMM slots
Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
Drive Bays Configuration
| Default: Total 92 bays
90 top-loading hot-swap 3.5"/2.5" SAS/SATA drive bays
2 top-loading fixed 2.5" SATA drive bays
M.2: 1 M.2 NVMe slot (M-key) |
| Expansion Slots | Default
3 PCIe 4.0 x16 LP slots |
| On-Board Devices | Chipset: Intel® C621A
Network Connectivity: 2 RJ45 10GBASE-T |
Input / Output
| LAN: 1 RJ45 1 GbE Dedicated BMC LAN port
2 RJ45 10 GBASE-T LAN ports
USB: 2 USB 3.0 ports(rear)
Video: 1 VGA port
DOM: 2 SuperDOM (Disk on Module) ports
|
System Cooling
| Fans: Up to 6 Heavy Duty 8cm Fan(s)
Air Shroud: 1 Air Shroud
|
Power Supply
| 2x 2600W Redundant Titanium Level (96%) Hot-plug power supplies
|
System BIOS
| BIOS Type: AMI 128MB SPI Flash EEPROM
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); Supermicro
SuperDoctor® 5 (SD5); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer
Automation Assistant (SAA) New!
|
PC Health Monitoring
| CPU: Monitors for CPU Cores, Chipset Voltages, Memory
4+1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment
Thermal Control for fan connectors
|
Dimensions and Weight
| Weight: Gross Weight: 240 lbs (108.86 kg)
Net Weight: 150 lbs (68.04 kg)
Available Color: Black
|
Operating Environment
| RoHS Compliant
Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (Non-Condensing)
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
|
