| Processor | 2 x Socket SP3 (LGA-4094)
Supports 3rd Gen AMD EPYC™ processors with AMD 3D V-Cache™ technology (up to 280W) |
| Memory | Total Slots 32 (8-channel per CPU)
Capacity Up to 4TB
Memory Type DDR4 3200 RDIMM/LRDIMM
Memory Size 128GB, 64GB, 32GB, 16GB
*Please refer to www.asus.com for latest memory AVL update |
| Expansion Slots | Total Slots 11
Slot Type Rear:
- 8 x PCIe x16 slots (Gen4 x16 link, FH,FL) for dual-slot GPU cards
- 1 x PCIe x16 slot (Gen4 x16/x8 link, FH,HL) or OCP3.0 NIC socket (optional)
- 1 x PCIe x8 slot (Gen4 x8 link, LP,HL) (optional)
Front:
- 1 x PCIe x16 slot (Gen4 x8 link, FH,HL) for HBA/RAID cards (optional) |
Storage Bays
| 8 x 2.5" or 3.5" Hot-swap Storage Bays
(Backplane Supports 4 x SATA/SAS + 4 x SATA/SAS/NVMe Devices*)
*for SATA/SAS drives support, an additional HBA/RAID card is required. |
| Networking | LAN 1 x dedicated management port (BMC AST2600) |
| Security | TPM / PFR Module (optional) |
| Front I/O Ports | 2 x USB 3.2 Gen1 ports
1 x VGA port
|
Rear I/O Ports
| 1 x Management port (RJ45)
|
Switch/LED
| Front :
1 x Power Button/LED
1 x Location Button/LED
1 x Message LED
1 x HDD Access LED
1 x Q-Code/Port 80 LED
1 x COM port (optional)
|
Management Solution
| Software ASUS Control Center (in-band)
Out of Band Remote
Management
ASMB10-iKVM (out-of-band/BMC AST2600)
|
Dimension
| 800mm x 439mm x 175.6mm (4U)
31.4” x 17.22” x 6.92”
|
Power Supply
| 2+2 Redundant 2200W 80 PLUS Platinum Power Supply or
2+2 Redundant 2200W 80 PLUS Titanium Power Supply or
2+2 Redundant 3000W 80 PLUS Titanium Power Supply
|
Environment
| Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing
|
