| Form Factor | 8U Rackmount
Enclosure: 449 x 351 x 800mm (17.6" x 13.8" x 31.5")
Package: 698 x 750 x 1300mm (27.5" x 29.5" x 51.2") |
Processor
| Dual Socket P+ (LGA-4189)
3rd Gen Intel® Xeon® Scalable processors |
| GPU | Max GPU Count: Up to 8 double-width GPUs
CPU-GPU Interconnect: PCIe 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect: NVIDIA® NVLink™ with NVSwitch |
System Memory
| Slot Count: 32 DIMM slots |
| On-Board Devices | Chipset: Intel® C621A
Network Connectivity: 2 RJ45 10GbE with Intel® X550-AT2 (optional) |
| Input / Output | 1 VGA port |
System Cooling
| Fans: Up to 4 heavy duty fans with optimal fan speed control
|
Power Supply
| 1x 3000W Redundant Titanium Level (96%) power supply
|
System BIOS
| BIOS Type: AMI 32MB SPI Flash EEPROM
|
Management
| SuperCloud Composer®; Supermicro Server Manager (SSM); Supermicro Update Manager (SUM); SuperDoctor® 5 (SD5); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); Automation Assistant (SAA) New!
|
Dimensions and Weight
| Weight: Gross Weight: 225 lbs (102.1 kg)
Net Weight: 166 lbs (75.3 kg)
Available Color: Black front & silver body
|
Operating Environment
| Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
|
