| Dimensions | 1U (W438 x H43.5 x D520 mm) |
CPU
| Intel® Xeon® E-2400 Processors
Intel® Pentium® Gold G7400 / G7400T Processor
Single processor, TDP up to 95W |
| Socket | 1 x LGA 1700 |
Chipset
| Intel® C262 Chipset |
| Memory | 4 x DIMM slots, 2-Channel DDR5
DIMM modules up to 32GB supported
ECC / non-ECC UDIMM modules supported only
Up to 4400MHz(1DPC), 4000MHz(2DPC/1R), 3600MHz(2DPC/2R) |
| LAN | 2 x 1Gb/s LAN ports (2 x Intel® I210-AT) - Support NCSI function
1 x 10/100/1000 management LAN |
Video
| Integrated in Aspeed AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
|
Storage
| 2 x 2.5" SATA hot-swappable bays
|
SAS
| N/A
|
RAID
| Intel® SATA RAID 0/1
|
Expansion Slots
| 1 x FHFL PCIe Gen5 x16 or 2 x FHFL PCIe Gen5 x8 slots
1 x FHHL PCIe Gen4 x4 slot
1 x M.2 slot: M-key, PCIe Gen4 x4, supports 2280/22110 cards
|
Front I/O
| 1 x USB 3.2 Gen1
|
Rear I/O
| 2 x USB 3.2 Gen1, 1 x Mini-DP, 2 x RJ45, 1 x MLAN
|
Backplane Board
| Speed and bandwidth: SATA 6Gb/s
|
| TPM | 1 x TPM header with SPI interface (Optional TPM2.0 kit: CTM010) |
Power Supply
| 1+1 800W 80 PLUS Titanium redundant power supplies
AC Input: 100-240V
|
| OS Compatibility | Windows Server 2019 / 2022
Red Hat Enterprise Linux server 8.6 / 9.0 (x64)
SUSE Linux Enterprise server 15 SP4 / 15 SP5
Ubuntu 20.04.6 LTS / Ubuntu 22.04.2 LTS (x64)
VMware ESXi 8.0
Citrix Hypervisor 8.2 LTSR CU1 |
| System Fan | 2 x 40x40x56mm (29,700rpm), 2 x 40x40x56mm (32,000rpm) |
| Operating Properties | Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing) |
| Packaging Content | 1 x E133-X10, 1 x CPU heatsink,
1 x Mini-DP to D-Sub cable |
