| Processor Support | 1 x Socket SP3 (LGA-4094)
Supports AMD EPYC™ 7003 series processors (up to 280W) |
Core Logic
| System on Chip (SoC) |
| GPU | GPU Baseboard Options:
HGX A100 4-GPU 40GB(160GB total) 400W
HGX A100 4-GPU 80GB(320GB total) 400W |
Memory
| Total Slots 16 (8-channel per CPU)
Capacity Maximum up to 4,096GB
Memory Type DDR4 3200 RDIMM/LR-DIMM/LR-DIMM 3DS
Memory Size 64GB, 32GB, 16GB(RDIMM), 128GB, 64GB(LRDIMM), 256GB, 128GB, 64GB(LRDIMM 3D)
*Refer to ASUS server AVL for the latest update |
| Expansion Slots | Total Slots 3
Slot Type 1 x PCIe x16 slot (Gen4 x16 link, FH,HL) or OCP3.0 NIC socket (optional)
2 x PCIe x16 slot (Gen4 x16 link, LP,HL) |
| Storage Bays | 4 x 3.5" Hot-swap Storage Bays (Backplane supports 4 x SATA/SAS/MVMe Devices)
1 x M.2 socket (Gen4 x4 link, up to 2280 module) |
Networking
| LAN 2 x 10GbE LAN ports (Intel X710-AT2)
1 x Dedicated management port (BMC AST2600)
|
Front I/O Ports
| 1 x USB 3.2 Gen1 ports
|
Rear I/O Ports
| 2 x USB 3.2 Gen1 port
2 x 10GbE LAN ports (RJ45)
1 x Management port (RJ45)
1 x VGA port
1 x COM port
|
Switch/LED
| Front:
1 x Power button/LED,
1 x Location button/LED
1 x Reset switch
1 x HDD Access LED
1 x Message LED
2 x LAN LED
Rear:
1 x Q-Code/Port 80 LED
1 x Power button/LED
1 x Location button/LED
|
Management
Solution
| Software ASUS Control Center (in-band)
Out of Band Remote Management ASMB10-iKVM (BMC AST2600)
|
Dimension
| 3U
823mm x 439.5mm x 130.6mm
|
Net Weight Kg (CPU, DRAM & HDD not included)
| 38 kg
|
Power Supply
| 1+1 Redundant
3000W 80 PLUS Titanium Power Supply
|
Environment
| Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
|
